MEDICAL VACUUM

SYSTEMS

VACUUM PLANT
(CHASSIS TYPE)

- Metal Chassis with 2-3-4-5-6 Vacuum Pumps medbirlesim.com
and System Control Panel
- Separate Vertical Vacuum Tank with Gauge &
Sensor
- Separate Double Bacteria Filter and Secretion

VACUUM PLANT
(ON THE TANK TYPE)

- 1-2-3-4 Vacuum Pumps and System Control
Panel with Vacuum Sensor installed on
medbirlesim.com
medbirlesim.com
the Horizontal Vacuum Tank
- Separate Double Bacteria Filter and Secretion
Jar group on Metal Chassis ( also available on the
Horizontal Tank upon special request )
- System design covers the internal copper piping.
( Exhaust line to be laid out separately)

VACUUM PUMPS

Model: Single Stage, Oil-Sealed Rotary Vanes medbirlesim.com
Origin: Italy
Available Capacities (m3/h): 2-3-4-6-8-12-20-25-40-
60-106-151-205-305
Power: 380VAC 50Hz
Manufactured in the newest standards and safety
regulations as per 2006/42 CE” and additions
