AREA VALVE &
SERVICE UNITS
MEDICAL GAS medbirlesim.com
ALARM
ZONE SERVICE -Audio/Visual Warning
UNITS
- LCD Screen for showing alarm status and
pressure/vacuum values
- On/Off valve group that physically disconnects the distribution line - 3 buttons to adjust and set the alarm
- Digital Alarm up to 6 gas lines - LED indicators of 6 gas lines for High/Normal/Low
- Pressure & Vacuum Transducers pressures
- Monoblock structure for each gas line - Compact back box with Input/outputs
medbirlesim.com
- Gauges for pressurized gas (0-10 Bar) and Vacuum (0/-1 Bar),
- Breakable Colored Lock Cover in Emergency
- Vertical Entry Pipes Ø15mm/Ø22mm medbirlesim.com medbirlesim.com
- without Pressure Regulators
- Metal Enclosure painted in Electrostatic Powder Coating
- S/s Enclosure optional
