PSA OXYGEN GENERATORS
ACTIVATED CARBON TOWER
MODEL CAPACITY AIR COMPRESSOR REFRIGERANT DRYER WS - P - G - H - D - C TYPE FILTER SERIES AIR TANK O2 TANK CONTAINER (OPTIONAL)
(OPTIONAL) Purity: 93% +/-3
VIP - Pneumatic Coaxial Valves
MED-50 50 Lt - 3 m³/h 0,76 m³/min(5,5kw) 1,20 m³/min(0,26 kw) 60,0 m³/h (½" ) WS 20 ¾" -120-180 m³/h 110 P-G-H / 65 C-D 500 LT 500 LT 6,5 mt -20'
Electrochemical O2 sensor with 3.5 mm jack input
MED-100 100 Lt - 6 m³/h 1,65 m³/min(11 kw) 2,50 m³/min(0,6k w) 110,0 m³/h (½" ) WS 20 ¾" -120-180 m³/h 110 P-G-H / 65 C-D 500 LT 500 LT 6,5 mt -20'
MED-150 150 Lt - 9 m³/h 2,50 m³/min(15 kw) 2,50 m³/min(0,6 kw) 150,0 m³/h (¾" ) WS 20 ¾" -120-180 m³/h 220 P-G-H / 65 C-D 750 LT 750 LT 6,5 mt -20' (Zirconium sensor upon special request)
Twin Zeolite Towers at the Back Side
MED-200 200 Lt - 12 m³/h 3,1 m³/min(18,5 kw) 3,60 m³/min(0,79 kw) 200,0 m³/h (1" ) WS 25 1" -180-280 m³/h 260 P-G-H / 110 C-D 1000 LT 1000 LT 6,5 mt -20'
Low Pressure Regulators at Input Side
MED-250 250 Lt - 15 m³/h 3,6 m³/min(22 kw) 5,40 m³/min(1 kw) 200,0 m³/h (1" ) WS 25 1" -180-280 m³/h 260 P-G-H / 110 C-D 1000 LT 1000 LT 6,5 mt -20'
Switching to standby when oxygen is not needed
MED-300 300 Lt - 18 m³/h 3,6 m³/min(22 kw) 5,40 m³/min(1 kw) 200,0 m³/h (1" ) WS 25 1" -180-280 m³/h 260 P-G-H / 110 C-D 1000 LT 1000 LT 6,5 mt -20'
Automatic operation in case of power failure,
MED-350 350 Lt - 21 m³/h 5,26 m³/min(30 kw) 6,50 m³/min(1,2kw) 300,0 m³/h (1 ½" ) WS 25 1" -180-280 m³/h 330 P-G-H / 110 C-D 1000 LT 1000 LT 6,5 mt -20'
when energy comes
MED-400 400 Lt - 24 m³/h 5,26 m³/min(30 kw) 6,50 m³/min(1,2kw) 300,0 m³/h (1 ½" ) WS 25 1" -180-280 m³/h 330 P-G-H / 110 C-D 1000 LT 1000 LT 6,5 mt -20'
7/24 nonstop working ability
MED-500 500 Lt - 30 m³/h 6,33 m³/min(37 kw) 7,70 m³/min(1,44 kw) 450,0 m³/h (1 ½" ) WS 25 1" -180-280 m³/h 530 P-G-H / 110 C-D 1000 LT 1000 LT 6,5 mt -20'
Connections: EN 13348 Medical Copper Tube
MED-600 600 Lt - 36 m³/h 7,61 m³/min(45 kw) 10 m³/min(1,8kw) 450,0 m³/h (1 ½" ) WS 25 1" -180-280 m³/h 630 P-G-H / 110 C-D 1000 LT 1000 LT 6,5 mt -20'
Remote access from all smart devices to the device
MED-700 700 Lt - 42 m³/h 9,33 m³/min(55 kw) 12 m³/min(1,8kw) 600,0 m³/h (1 ½" ) WS 40 1 ½" -280-660 m³/h 630 P-G-H / 110 C-D 2000 LT 2000 LT 6,5 mt -20'
7” Touch Screen Control Panel
MED-800 800 Lt - 48 m³/h 9,33 m³/min(55 kw) 12 m³/min(1,8kw) 600,0 m³/h (1 ½" ) WS 40 1 ½" -280-660 m³/h 630 P-G-H / 110 C-D 2000 LT 2000 LT 13 mt -40'
PLC Controller with Integrated HMI
MED-900 900 Lt - 54 m³/h 12,38 m³/min(75 kw) 15 m³/min(2,6kw) 600,0 m³/h (1 ½" ) WS 40 1 ½" -280-660 m³/h 930 P-G-H / 220 C-D 2000 LT 2000 LT 13 mt -40'
MED-1000 1000 Lt - 60 m³/h 12,38 m³/min(75 kw) 15 m³/min(2,6kw) 600,0 m³/h (1 ½" ) WS 40 1 ½" -280-660 m³/h 3000 LT 3000 LT 13 mt -40'
MED-1100 1100 Lt - 66 m³/h 12,38 m³/min(75 kw) 18 m³/min(3,5kw) 600,0 m³/h (1 ½" ) WS 40 1 ½" -280-660 m³/h 930 P-G-H / 220 C-D 3000 LT 3000 LT 13 mt -40'
MED-1200 1200 Lt - 72 m³/h 16,3 m³/min(90 kw) 18 m³/min(3,5kw) 900,0 m³/h (2" ) WS 40 1 ½" -280-660 m³/h 1230 P-G-H / 220 C-D 3000 LT 3000 LT 13 mt -40'
medbirlesim.com
MED-1300 1300 Lt - 78 m³/h 16,3 m³/min(90 kw) 24 m³/min(3,9kw) 900,0 m³/h (2" ) WS 40 1 ½" -280-660 m³/h 1230 P-G-H / 220 C-D 3000 LT 3000 LT 13 mt -40'
MED-1400 1400 Lt - 84 m³/h 18,5 m³/min(110 kw) 24 m³/min(3,9kw) 1200,0 m³/h (2" ) WS 50 2" -660-1200 m³/h 1230 P-G-H / 220 C-D 3000 LT 3000 LT 13 mt -40'
MED-1500 1500 Lt - 90 m³/h 18,5 m³/min(110 kw) 24 m³/min(3,9kw) 1200,0 m³/h (2" ) WS 50 2" -660-1200 m³/h 1230 P-G-H / 220 C-D 5000 LT 5000 LT 13 mt -40'
MED-1600 1600 Lt - 96 m³/h 18,5 m³/min(110 kw) 30 m³/min(4,45kw) 1200,0 m³/h (2" ) WS 50 2" -660-1200 m³/h 1230 P-G-H / 220 C-D 5000 LT 5000 LT 13 mt -40'
MED-1700 1700 Lt - 102 m³/h 23,8 m³/min(132kw) 30 m³/min(4,45kw) 1200,0 m³/h (2" ) WS 50 2" -660-1200 m³/h 1230 P-G-H / 220 C-D 5000 LT 5000 LT 13 mt -40'
MED-1800 1800 Lt - 108 m³/h 23,8 m³/min(132kw) 30 m³/min(4,45kw) 1200,0 m³/h (2" ) WS 50 2" -660-1200 m³/h 1500 P-G-H / 260 C-D 5000 LT 5000 LT 13 mt -40'
MED-1900 1900 Lt - 114 m³/h 23,8 m³/min(132kw) 30 m³/min(4,45kw) 1200,0 m³/h (2" ) WS 50 2" -660-1200 m³/h 1500 P-G-H / 260 C-D 5000 LT 5000 LT 13 mt -40'
5000 LT
5000 LT
MED-2000 2000 Lt - 120 m³/h 23,8 m³/min(132kw) 30 m³/min(4,45kw) 1200,0 m³/h (2" ) WS 50 2" -660-1200 m³/h 1500 P-G-H / 260 C-D medbirlesim.com medbirlesim.com
13 mt -40'
